An Introduction to tidymodels

Max Kuhn

topepo.github.io/2023-latinR

Modeling in R

  • R has always had a rich set of modeling tools that it inherited from S. For example, the formula interface has made it simple to specify potentially complex model structures.

  • R has cutting-edge models. Many researchers in various domains use R as their primary computing environment and their work often results in R packages.

  • It is easy to port or link to other applications. R doesn’t try to be everything to everyone.

Modeling in R

However, there is a huge consistency problem. For example:

  • There are two primary methods for specifying what terms are in a model. Not all models have both.
  • 99% of model functions automatically generate dummy variables.
  • Many package developers don’t know much about the language and omit OOP and other core R components.

Two examples follow…

Between-Package Inconsistency

The syntax for computing predicted class probabilities:

  • MASS package: predict(lda_fit)
  • stats package: predict(glm_fit, type = "response")
  • mda package: type = "posterior"
  • rpart package: type = "prob"
  • RWeka package: type = "probability"

and so on.

Model Interfaces

Which of these packages has both a formula and non-formula (x/y) interface to the model?

  • glmnet
  • ranger
  • rpart
  • survival
  • xgboost

Model Interfaces

Which of these packages has both a formula and non-formula (x/y) interface to the model?

  • glmnet (matrix only)
  • ranger (both but weirdly)
  • rpart (formula only)
  • survival (formula only)
  • xgboost (special sparse matrix only, classes are zero-based integers)

Is there such a thing as a systems statistician?

tidymodels: Our job is to make modeling data with R less frustrating better.

It’s actually pretty good

“Modeling” includes everything from classical statistical methods to machine learning.

The Tidyverse

All tidyverse packages share an underlying design philosophy, grammar, and data structures.

The principles of the tidyverse:

  1. Reuse existing data structures.
  2. Compose simple functions with the pipe.
  3. Embrace functional programming.
  4. Design for humans.

This results in more specific conventions around interfaces, function naming, etc.

The Tidyverse

For example, we try to use common prefixes for auto-complete: tune_grid(), tune_bayes(), …

There is also the notion of tidy data:

  1. Each variable forms a column.
  2. Each observation forms a row.
  3. Each type of observational unit forms a table.

Based on these ideas, we can create modeling packages that have predictable results and are a pleasure to use.

Tidymodels

tidymodels is a collection of modeling packages that are designed in the same spirit as the tidyverse.

My goals for tidymodels are:

  1. Smooth out diverse interfaces.

  2. Encourage empirical validation

  3. Quietly coerce good data usage.

  4. Build highly reusable infrastructure.

  5. Enable a wider variety of methodologies.

Leveling Up Our Tools

  • more categorical econding methods
    • effect encoding methods
    • feature hashing
    • multiple choice predictors
  • modern dimension reduction
    • UMAP
    • manifold-based multidimensional scaling
  • additional imputation tools

etcetera

tidymodels.org

Tidy Modeling with R

(tmwr.org)

workshops.tidymodels.org

library(tidymodels)
#> ── Attaching packages ────────────────────────────────────── tidymodels 1.1.1 ──
#> ✔ broom        1.0.5     ✔ recipes      1.0.7
#> ✔ dials        1.2.0     ✔ rsample      1.2.0
#> ✔ dplyr        1.1.3     ✔ tibble       3.2.1
#> ✔ ggplot2      3.4.3     ✔ tidyr        1.3.0
#> ✔ infer        1.0.4     ✔ tune         1.1.2
#> ✔ modeldata    1.2.0     ✔ workflows    1.1.3
#> ✔ parsnip      1.1.1     ✔ workflowsets 1.0.1
#> ✔ purrr        1.0.2     ✔ yardstick    1.2.0
#> ── Conflicts ───────────────────────────────────────── tidymodels_conflicts() ──
#> ✖ purrr::accumulate() masks foreach::accumulate()
#> ✖ purrr::discard()    masks scales::discard()
#> ✖ dplyr::filter()     masks stats::filter()
#> ✖ dplyr::lag()        masks stats::lag()
#> ✖ recipes::step()     masks stats::step()
#> ✖ purrr::when()       masks foreach::when()
#> • Use tidymodels_prefer() to resolve common conflicts.

tidymodels_prefer()

Example Data

Let’s look at some data on delivery times for a restaurant.

(n = 10,012)

We want to predict the time_to_delivery based on some basic predictors.

  • order_time (double)
  • order_day (factor)
  • distance (double)
  • item_01, …, item_27 (counts)

Outcome distribution

deliveries %>%
  ggplot(aes(time_to_delivery)) +
  geom_histogram(col = "white") +
  geom_rug(alpha = .1)

Splitting the data

We’ll split the data into training (60%), validation (20%), and testing (20%).

Stratification helps ensure the three outcome distributions are about the same.

set.seed(91)
delivery_split <-
  initial_validation_split(deliveries,
                           prop = c(0.6, 0.2),
                           strata = time_to_delivery)

delivery_split
#> <Training/Validation/Testing/Total>
#> <6004/2004/2004/10012>

delivery_train <- training(delivery_split)
delivery_val <- validation(delivery_split)

# To treat it as a single resample:
delivery_rs <- validation_set(delivery_split)

A Nonlinear Effect

delivery_train %>%
  ggplot(aes(order_time, time_to_delivery)) +
  geom_smooth() +
  ylim(c(10, 32))

Actually A Nonlinear Interaction

delivery_train %>%
  ggplot(aes(order_time, time_to_delivery, col = order_day)) +
  geom_smooth() +
  ylim(c(10, 32))

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train)


This just initializes the recipe by recording column roles and types.

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train) %>%
  step_dummy(order_day)


Each step_ function takes dplyr selectors.

The default naming is much better (e.g., order_day_Fri).


There are many steps that encode categorical predictors. See Encoding Categorical Data in Tidy Models with R.

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train) %>%
  step_dummy(all_factor_predictors())

Other selectors are:

  • all_nominal(), all_numeric(), and has_type()

  • all_predictors(), all_outcomes(), and has_role()

  • all_numeric_predictors() and all_nominal_predictors() too

  • Standard dplyr selectors like starts_with() and so on.

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train) %>%
  step_dummy(all_factor_predictors()) %>%
  step_zv(all_predictors())

Removes any predictor columns with a single unique value (i.e., “zv” = zero-variance).

There is also a step for nearly zero-variance columns.

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train) %>%
  step_dummy(all_factor_predictors()) %>%
  step_zv(all_predictors()) %>%
  step_spline_natural(order_time, deg_free = 5)

There are a variety of basis expansion steps. This creates additional columns in the data set.

Why 5 degrees of freedom?

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train) %>%
  step_dummy(all_factor_predictors()) %>%
  step_zv(all_predictors()) %>%
  step_spline_natural(order_time, deg_free = tune())

We can optimize the degrees of freedom using model tuning.

We’ll stick with 5 for now.


Remember that our nonlinear patterns depend on the day?

The day indicators are named order_day_{level}.

We should make interaction terms!

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train) %>%
  step_dummy(all_factor_predictors()) %>%
  step_zv(all_predictors()) %>%
  step_spline_natural(order_time, deg_free = 5) %>%
  step_interact(~ starts_with("order_day"):starts_with("order_time"))

This selects all of the correct indicator values and crosses them with all of the spline model terms.

What are our features?

delivery_rec <-
  recipe(time_to_delivery ~ ., data = delivery_train) %>%
  step_dummy(all_factor_predictors()) %>%
  step_zv(all_predictors()) %>%
  step_spline_natural(order_time, deg_free = 5) %>%
  step_interact(~ starts_with("order_day"):starts_with("order_time")) %>%
  step_normalize(all_numeric_predictors())


Let’s fit a linear regression model!

With parsnip, we first create an object that specifies the type of model and then the software engine to do the fit.

Linear regression specification

linear_mod <-
  linear_reg()

# Defaults to `lm()`

This says “Let’s fit a model with a numeric outcome, and intercept, and slopes for each predictor.”

  • Other model types include nearest_neighbors(), decision_tree(), arima_reg(), and so on.

The set_engine() function gives the details on how it should be fit.

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("lm")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("keras")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("brulee")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("spark")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("stan")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("glmnet")

Let’s fit it with…

linear_mod <-
  linear_reg(penalty = 0.1,
             mixture = 0.5) %>%
  set_engine("glmnet")

A modeling workflow

We can optionally bundle the recipe and model together into a pipeline workflow:

glmnet_wflow <-
  workflow() %>%
  add_model(linear_mod) %>%
  add_recipe(delivery_rec) # or add_formula() or add_variables()

Fitting and prediction are very easy:

glmnet_fit <- fit(glmnet_wflow, data = delivery_train)

# Very east to use compared to glmnet::predict():
predict(glmnet_fit, delivery_val %>% slice(1:5))
#> # A tibble: 5 × 1
#>   .pred
#>   <dbl>
#> 1  23.4
#> 2  15.3
#> 3  31.5
#> 4  20.8
#> 5  28.1

A Better Interface

fit_resamples() uses the out-of-sample data to estimate performance:

ctrl <- control_resamples(save_pred = TRUE)
glmnet_res <- glmnet_wflow %>%
  # We can use our validation set!
  fit_resamples(resamples = delivery_rs, control = ctrl)

collect_metrics(glmnet_res)
#> # A tibble: 2 × 6
#>   .metric .estimator  mean     n std_err .config
#>   <chr>   <chr>      <dbl> <int>   <dbl> <chr>
#> 1 rmse    standard   2.36      1      NA Preprocessor1_Model1
#> 2 rsq     standard   0.885     1      NA Preprocessor1_Model1

Plot the Data!

The only way to be comfortable with your data is to never look at them.

library(probably)
glmnet_res %>% cal_plot_regression(alpha = 1/5)

But What About Those parameters?

We probably don’t have a good idea of what deg_free, penalty, and mixture should be.

As seen before, we could mark them for tuning and optimize them.

Instead, we’ll try a different model and show how to tune the model.

Let’s Try Cubist.

It is a rule-based ensemble. Rules are paths through a tree. Here are 4 rules:

It can create many rule sets to form an ensemble.

Example Rules

if
    order_time <= 13.715
    order_day in {Fri, Sat}
    distance <= 5.08
then
    outcome = -24.3334 + 2.97 order_time + 1.13 distance + 0.6 item_10
              + 0.4 item_09 + 0.6 item_21 + 0.5 item_01 + 0.3 item_24
              + 0.3 item_08 + 0.3 item_03 + 0.3 item_13 + 0.2 item_02
              + 0.2 item_07
if
    order_time > 20.038
    order_day = Sat
then
    outcome = 47.04085 - 1.45 order_time + 3.38 distance + 1.6 item_08

Model tuning

library(rules)
cubist_mod <- cubist_rules(committees = tune())
cubist_wflow <- workflow(time_to_delivery ~ ., cubist_mod)


We’ll evaluate 25 model candidates using a space-filling design and evaluate them on the validation set:

cubist_res <-
  cubist_wflow %>%
  tune_grid(resamples = delivery_rs, grid = 10)

show_best(cubist_res, metric = "rmse", n = 3)
#> # A tibble: 3 × 7
#>   committees .metric .estimator  mean     n std_err .config
#>        <int> <chr>   <chr>      <dbl> <int>   <dbl> <chr>
#> 1         96 rmse    standard    1.98     1      NA Preprocessor1_Model05
#> 2         44 rmse    standard    1.98     1      NA Preprocessor1_Model02
#> 3         28 rmse    standard    1.98     1      NA Preprocessor1_Model08

Model tuning

autoplot(cubist_res, metric = "rmse")

Next Steps

From here, we would

  • tune a variety of models and/or recipes
  • pick a model that we like the most
  • finalize the model’s tuning parameters
  • fit it to the entire training set
  • verify the results with the test set

The last three steps can be done with a single function called last_fit().

Other tools

Some other things to do with these data:

Development

Recent updates:

  • censored data models (a.k.a survival analysis)
  • case weights
  • conformal inference tools for prediction intervals

In-process:

  • model fairness metrics and modeling techniques
  • causal inference methods
  • a general set of post-processing tools

Thanks

Thanks for the invitation to speak today and sharing your Mate!


The tidymodels team: Hannah Frick, Emil Hvitfeldt, and Simon Couch.


Special thanks to the other folks who contributed so much to tidymodels: Davis Vaughan, Julia Silge, Edgar Ruiz, Alison Hill, Desirée De Leon, our previous interns, and the tidyverse team.

https://topepo.github.io/2023-latinR
