(tidy)Modeling Workshop

Max Kuhn

About me

Becton-Dickinson (6y): molecular diagnostics for infectious diseases, non-clinical and clinical
Pfizer (12y): nonclinical, Med chem, Comp {bio,chem} support
~~RStudio~~ posit PBC (>= 2016): modeling packages

Selected R packages: caret, C50, Cubist, a lot of tidymodels

Modeling in R

R has always had a rich set of modeling tools that it inherited from S. For example, the formula interface has made it simple to specify potentially complex model structures.
R has cutting-edge models. Many researchers in various domains use R as their primary computing environment and their work often results in R packages.
It is easy to port or link to other applications. R doesn’t try to be everything to everyone.

Modeling in R

However, there is a huge consistency problem. For example:

There are two primary methods for specifying what terms are in a model. Not all models have both.
99% of model functions automatically generate dummy variables.
Many package developers don’t know much about the language and omit OOP and other core R components.

Two examples follow…

Between-Package Inconsistency

The syntax for computing predicted class probabilities:

MASS package: predict(lda_fit)
stats package: predict(glm_fit, type = "response")
gbm package: predict(gbm_fit, type = "response", n.trees)
mda package: predict(mda_fit, type = "posterior")
rpart package: predict(rpart_fit, type = "prob")
RWeka package: predict(bagging_fit, type = "probability")
pamr package: pamr.predict(pamr_fit, type = "posterior")

Within-Package Inconsistency: `glmnet` Predictions

The glmnet model can be used to fit regularized generalized linear models with a mixture of L₁ and L₂ penalties.

We’ll look at what happens when we get predictions for a regression model (i.e. numeric Y) as well as classification models where Y has two or three categorical values.

The models shown below contain solutions for three regularization values ( \(\lambda\) ).
The predict method gives the results for all three at once (👍).

Numeric `glmnet` Predictions

Predicting a numeric outcome for two new data points:

new_x
#>             x1     x2     x3     x4
#> sample_1 1.649 -0.483 -0.294 -0.815
#> sample_2 0.656 -0.420  0.880  0.109

predict(reg_mod, newx = new_x)
#>          s0 s1 s2
#> sample_1 10 10 10
#> sample_2 10 10 10

A matrix result and we will assume that the \(\lambda\) values are in the same order as what we gave to the model fit function.

`glmnet` predictions formats

Numeric model, numeric prediction

numeric sample x penalty array

Binary model, class prediction

character sample x penalty array

Binary model, probability prediction

numeric sample x penalty array (values are 2nd factor level)

Multinomial model, probability prediction

numeric class x sample x penalty array

`glmnet` predictions formats

😳

Most people have at least four different scripts for the same model

Am I working for glmnet or is it is working for me?

Maybe a structure like this would work better:

#> # A tibble: 6 × 5
#>       a     b     c lambda  .row
#>   <dbl> <dbl> <dbl>  <dbl> <int>
#> 1 0.373 0.244 0.383 0.01       1
#> 2 0.327 0.339 0.334 0.01       1
#> 3 0.389 0.220 0.391 0.001      2
#> 4 0.326 0.337 0.338 0.001      2
#> 5 0.390 0.217 0.392 0.0001     3
#> 6 0.326 0.336 0.338 0.0001     3

tidymodels: Our job is to make modeling data with R suck less better.

It’s actually pretty good

“Modeling” includes everything from classical statistical methods to machine learning.

The Tidyverse

The tidyverse is an opinionated collection of R packages designed for data science. All packages share an underlying design philosophy, grammar, and data structures.

The principles of the tidyverse:

Reuse existing data structures.
Compose simple functions with the pipe.
Embrace functional programming.
Design for humans.

This results in more specific conventions around interfaces, function naming, etc.

The Tidyverse

For example, we try to use common prefixes for auto-complete: tune_grid(), tune_bayes(), …

There is also the notion of tidy data:

Each variable forms a column.
Each observation forms a row.
Each type of observational unit forms a table.

Based on these ideas, we can create modeling packages that have predictable results and are a pleasure to use.

Tidymodels

tidymodels is a collection of modeling packages that live in the tidyverse and are designed in the same way.

My goals for tidymodels are:

Encourage empirical validation and good methodology.
Smooth out diverse interfaces.
Build highly reusable infrastructure.
Enable a wider variety of methodologies.

`tidymodels.org`

Tidy Modeling with R (`tmwr.org`)

Selected Modeling Packages

broom takes the messy output of built-in functions in R, such as lm, nls, or t.test, and turns them into tidy data frames.
recipes is a general data preprocessor with a modern interface. It can create model matrices that incorporate feature engineering, imputation, and other tools.
rsample has infrastructure for resampling data so that models can be assessed and empirically validated.
parsnip gives us a unified modeling interface.
tune has functions for grid search and sequential optimization of model parameters.

Loading the Meta-Package

library(tidymodels)
tidymodels_prefer()

data(Chicago, package = "modeldata")

Let’s start by predicting the ridership of the Chicago “L” trains.

We have data over 5,698 days between 2001 and 2016 in Chicago.

What are our predictors? Date, weather data, home game schedules, 14-day lags at other stations.

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago)

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year"))

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date)

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date) %>%
  update_role(date, new_role = "id")

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date) %>%
  update_role(date, new_role = "id") %>%
  step_dummy(all_nominal_predictors())

Other selectors are:

all_nominal(), all_numeric(), and has_type()
all_predictors(), all_outcomes(), and has_role()
all_numeric_predictors() and all_nominal_predictors() too
Standard dplyr selectors like starts_with() and so on.

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date) %>%
  update_role(date, new_role = "id") %>%
  step_dummy(all_nominal_predictors()) %>%
  step_normalize(all_numeric_predictors())

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date) %>%
  update_role(date, new_role = "id") %>%
  step_dummy(all_nominal_predictors()) %>%
  step_normalize(all_numeric_predictors()) %>%
  step_pca(one_of(stations), num_comp = 10)

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date) %>%
  update_role(date, new_role = "id") %>%
  step_dummy(all_nominal_predictors()) %>%
  step_normalize(all_numeric_predictors()) %>%
  # In the embed package:
  step_umap(one_of(stations), outcome = vars(ridership), num_comp = 10)

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date) %>%
  update_role(date, new_role = "id") %>%
  step_dummy(all_nominal_predictors()) %>%
  step_normalize(all_numeric_predictors()) %>%
  step_spline_natural(Harlem, deg_free = 5)

What are our features?

chicago_rec <- recipe(ridership ~ ., data = Chicago) %>%
  step_date(date, features = c("dow", "month", "year")) %>%
  step_holiday(date) %>%
  update_role(date, new_role = "id") %>%
  step_dummy(all_nominal_predictors()) %>%
  step_normalize(all_numeric_predictors()) %>%
  step_mutate(temp = (32 * temp - 32) * 5 / 9 )

Let’s fit a linear regression model!

With parsnip, we first create an object that specifies the type of model and then the software engine to do the fit.

Linear regression specification

linear_mod <- linear_reg()

# Defaults to `lm()`

This says “Let’s fit a model with a numeric outcome, and intercept, and slopes for each predictor.”

Other model types include nearest_neighbors(), decision_tree(), rand_forest(), arima_reg(), and so on.

The set_engine() function gives the details on how it should be fit.

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("lm")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("keras")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("brulee")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("spark")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("stan")

Let’s fit it with…

linear_mod <-
  linear_reg() %>%
  set_engine("glmnet")

Let’s fit it with…

linear_mod <-
  linear_reg(penalty = 0.1, mixture = 0.5) %>%
  set_engine("glmnet")

A modeling workflow

We can optionally bundle the recipe and model together into a ~~pipeline~~ workflow:

glmnet_wflow <-
  workflow() %>%
  add_model(linear_mod) %>%
  add_recipe(chicago_rec) # or add_formula() or add_variables()

Fitting and prediction are very easy:

glmnet_fit <- fit(glmnet_wflow, data = Chicago)

# Very east to use compared to glmnet::predict():
predict(glmnet_fit, Chicago %>% slice(1:7))
#> # A tibble: 7 × 1
#>   .pred
#>   <dbl>
#> 1 13.8
#> 2 15.0
#> 3 14.7
#> 4 14.6
#> 5 14.1
#> 6  2.36
#> 7  1.73

Model tuning

We probably don’t have a good idea of what the penalty and mixture values should be.

We can mark them for tuning :

linear_mod <-
  linear_reg(penalty = tune(), mixture = tune()) %>%
  set_engine("glmnet")

glmnet_wflow <-
  glmnet_wflow %>%
  update_model(linear_mod)

Recipe arguments can also be simultaneously tuned (e.g. num_comp in step_pca()).

Example: Predicting cognitive function

Craig-Schapiro et al. (2011) describe a clinical study of 333 patients (cognitive impairment or healthy).

CSF samples were taken from all subjects. Data collected on each subject included:

Demographic characteristics such as age and gender
Apolipoprotein E genotype
Protein measurements of Aβ, Tau, and a phosphorylated version of Tau (pTau)
Protein measurements of 124 exploratory biomarkers, and
Clinical dementia scores

The data

There is some class imbalance:

data(ad_data, package = "modeldata")
dim(ad_data)
#> [1] 333 131
count(ad_data, Class)
#> # A tibble: 2 × 2
#>   Class        n
#>   <fct>    <int>
#> 1 Impaired    91
#> 2 Control    242

We’ll use stratified sampling to split the data to maintain the frequency distribution.

Data splitting

The initial training/test split (3:1) and resampling via the bootstrap:

set.seed(12)
ad_split <- initial_split(ad_data, strata = Class)
ad_train <- training(ad_split)
ad_test  <- testing(ad_split)
ad_boot <- bootstraps(ad_train, times = 50, strata = Class)

ad_boot %>% slice(1) %>% pluck("splits") %>% pluck(1) %>% analysis() %>% count(Class)
#> # A tibble: 2 × 2
#>   Class        n
#>   <fct>    <int>
#> 1 Impaired    68
#> 2 Control    181

We’ll use the bootstrap to measure performance during tuning.

Model and recipe

Let’s fit a neural network and use a simple recipe that standardizes the predictors.

We’ll tune three model parameters:

nnet_mod <-
  mlp(hidden_units = tune(), penalty = tune(), epochs = tune()) %>%
  set_mode("classification")

nnet_rec <-
  recipe(Class ~ ., data = ad_train) %>%
  step_dummy(Genotype) %>%
  step_zv(all_predictors()) %>%
  step_normalize(all_predictors())

Model tuning via racing

We’ll use a tool called racing to tune a large number of model configurations efficiently.

library(finetune)

set.seed(8239)
nnet_tune_res <-
  nnet_mod %>%
  tune_race_anova(
    nnet_rec,
    resamples = ad_boot,
    grid = 50,
    control = control_race(verbose_elim = TRUE, save_pred = TRUE)
  )

This only fits a fraction of the possible 2500 possible models via efficient interim analysis.

Racing process

Check predictions

Let’s take the model with the largest ROC AUC as best:

show_best(nnet_tune_res, metric = "roc_auc")
#> # A tibble: 1 × 9
#>   hidden_units penalty epochs .metric .estimator  mean     n std_err .config
#>          <int>   <dbl>  <int> <chr>   <chr>      <dbl> <int>   <dbl> <chr>
#> 1            2   0.765    978 roc_auc binary     0.879    50 0.00468 Preprocess…

best_nnet <- select_best(nnet_tune_res, metric = "roc_auc")
best_nnet
#> # A tibble: 1 × 4
#>   hidden_units penalty epochs .config
#>          <int>   <dbl>  <int> <chr>
#> 1            2   0.765    978 Preprocessor1_Model19

oob_pred <- collect_predictions(nnet_tune_res, parameters = best_nnet)

The predictions are averages of the out-of-sample predictions,

Check predictions

So the model separates the classes but are the probabilities well-calibrated?

Yeah but no. Let’s mitigate the issue via post-processing using a few different methods.

Logistic calibration

set.seed(283)
resampled_pred <- oob_pred %>% vfold_cv()

resampled_pred %>%
  cal_validate_logistic(truth = Class) %>%
  collect_metrics()
#> # A tibble: 2 × 7
#>   .metric     .type        .estimator  mean     n std_err .config
#>   <chr>       <chr>        <chr>      <dbl> <int>   <dbl> <chr>
#> 1 brier_class uncalibrated binary     0.152    10 0.00163 config
#> 2 brier_class calibrated   binary     0.120    10 0.00296 config

The Brier score is a good metric to assess how well the model is calibrated.

A value of zero is best and a really bad model for two classes has a value of (1 - (1/2))^2 = 0.25.

Isotonic calibration

resampled_pred %>%
  cal_validate_isotonic(truth = Class) %>%
  collect_metrics()
#> # A tibble: 2 × 7
#>   .metric     .type        .estimator  mean     n std_err .config
#>   <chr>       <chr>        <chr>      <dbl> <int>   <dbl> <chr>
#> 1 brier_class uncalibrated binary     0.152    10 0.00163 config
#> 2 brier_class calibrated   binary     0.121    10 0.00321 config

Beta calibration

resampled_pred %>%
  cal_validate_beta(truth = Class) %>%
  collect_metrics()
#> # A tibble: 2 × 7
#>   .metric     .type        .estimator  mean     n std_err .config
#>   <chr>       <chr>        <chr>      <dbl> <int>   <dbl> <chr>
#> 1 brier_class uncalibrated binary     0.152    10 0.00163 config
#> 2 brier_class calibrated   binary     0.122    10 0.00285 config

We’ll try using the logistic model.

Does it work?

ad_cal <-
  cal_estimate_logistic(oob_pred, truth = Class)

calibrated_pred <-
  oob_pred %>%
  cal_apply(ad_cal)

calibrated_pred %>%
  cal_plot_windowed(truth = Class,
                    estimate = .pred_Impaired,
                    step_size = 0.025)

Exercise!

You have two options:

Try adding a feature extraction method (one example being PCA) to the recipe and also optimize its parameters.

… or …

Use sub-sampling methods for class imbalances to pre-process the data.

How do we find the possible recipe steps?

Picking a final model

Normally, after searching through models, we pick one that we think should go forward.

nnet_wflow <-
  nnet_rec %>%
  workflow(nnet_mod) %>%
  finalize_workflow(best_nnet)
nnet_wflow
#> ══ Workflow ════════════════════════════════════════════════════════════════════
#> Preprocessor: Recipe
#> Model: mlp()
#>
#> ── Preprocessor ────────────────────────────────────────────────────────────────
#> 3 Recipe Steps
#>
#> • step_dummy()
#> • step_zv()
#> • step_normalize()
#>
#> ── Model ───────────────────────────────────────────────────────────────────────
#> Single Layer Neural Network Model Specification (classification)
#>
#> Main Arguments:
#>   hidden_units = 2
#>   penalty = 0.764635581502846
#>   epochs = 978
#>
#> Computational engine: nnet

Fitting the final model

Let’s fit a model of ours on the the entire training set.

If we originally used initial_split(), we can also use last_fit() to do this:

test_res <-
  nnet_wflow %>%
  last_fit(split = ad_split)

extract_fit_engine(test_res)
#> a 134-2-1 network with 273 weights
#> inputs: ACE_CD143_Angiotensin_Converti ACTH_Adrenocorticotropic_Hormon AXL Adiponectin Alpha_1_Antichymotrypsin Alpha_1_Antitrypsin Alpha_1_Microglobulin Alpha_2_Macroglobulin Angiopoietin_2_ANG_2 Angiotensinogen Apolipoprotein_A_IV Apolipoprotein_A1 Apolipoprotein_A2 Apolipoprotein_B Apolipoprotein_CI Apolipoprotein_CIII Apolipoprotein_D Apolipoprotein_E Apolipoprotein_H B_Lymphocyte_Chemoattractant_BL BMP_6 Beta_2_Microglobulin Betacellulin C_Reactive_Protein CD40 CD5L Calbindin Calcitonin CgA Clusterin_Apo_J Complement_3 Complement_Factor_H Connective_Tissue_Growth_Factor Cortisol Creatine_Kinase_MB Cystatin_C EGF_R EN_RAGE ENA_78 Eotaxin_3 FAS FSH_Follicle_Stimulation_Hormon Fas_Ligand Fatty_Acid_Binding_Protein Ferritin Fetuin_A Fibrinogen GRO_alpha Gamma_Interferon_induced_Monokin Glutathione_S_Transferase_alpha HB_EGF HCC_4 Hepatocyte_Growth_Factor_HGF I_309 ICAM_1 IGF_BP_2 IL_11 IL_13 IL_16 IL_17E IL_1alpha IL_3 IL_4 IL_5 IL_6 IL_6_Receptor IL_7 IL_8 IP_10_Inducible_Protein_10 IgA Insulin Kidney_Injury_Molecule_1_KIM_1 LOX_1 Leptin Lipoprotein_a MCP_1 MCP_2 MIF MIP_1alpha MIP_1beta MMP_2 MMP_3 MMP10 MMP7 Myoglobin NT_proBNP NrCAM Osteopontin PAI_1 PAPP_A PLGF PYY Pancreatic_polypeptide Prolactin Prostatic_Acid_Phosphatase Protein_S Pulmonary_and_Activation_Regulat RANTES Resistin S100b SGOT SHBG SOD Serum_Amyloid_P Sortilin Stem_Cell_Factor TGF_alpha TIMP_1 TNF_RII TRAIL_R3 TTR_prealbumin Tamm_Horsfall_Protein_THP Thrombomodulin Thrombopoietin Thymus_Expressed_Chemokine_TECK Thyroid_Stimulating_Hormone Thyroxine_Binding_Globulin Tissue_Factor Transferrin Trefoil_Factor_3_TFF3 VCAM_1 VEGF Vitronectin von_Willebrand_Factor age tau p_tau Ab_42 male Genotype_E2E3 Genotype_E2E4 Genotype_E3E3 Genotype_E3E4 Genotype_E4E4
#> output(s): ..y
#> options were - entropy fitting  decay=0.765

Test set evaluation

Ordinarily, we would use collect_metrics() on this to get our test set results.

However, we have to apply the calibration the test set predictions first:

test_pred <-
  test_res %>%
  collect_predictions() %>%
  cal_apply(ad_cal)

cls_metrics <- metric_set(roc_auc, brier_class)
cls_metrics(test_pred, Class, .pred_Impaired)
#> # A tibble: 2 × 3
#>   .metric     .estimator .estimate
#>   <chr>       <chr>          <dbl>
#> 1 roc_auc     binary         0.860
#> 2 brier_class binary         0.127

Test set ROC curve

test_pred %>%
  roc_curve(Class, .pred_Impaired) %>%
  autoplot()

Test set calibration curve

test_pred %>%
  cal_plot_windowed(truth = Class,
                    estimate = .pred_Impaired,
                    step_size = 0.025)

Next steps

If this model was best, we would fit the model on the entire training set (via the last_fit()) function the measure performance on the test set.

Some other things to do with these data:

Other extensions

censored data models (a.k.a survival analysis)
case weights
conformal inference tools for prediction intervals

In-process:

model fairness metrics and modeling techniques
causal inference methods
a general set of post-processing tools

Thanks

Thanks for the invitation to speak today!

The tidymodels team: Hanna Frick, Emil Hvitfeldt, and Simon Couch.

Special thanks to the other folks who contributed so much to tidymodels: Davis Vaughan, Edgar Ruiz, Alison Hill, Desirée De Leon, our previous interns, and the tidyverse team.

(tidy)Modeling Workshop

About me

Modeling in R

Modeling in R

Between-Package Inconsistency

Within-Package Inconsistency: glmnet Predictions

Numeric glmnet Predictions

glmnet predictions formats

glmnet predictions formats

tidymodels: Our job is to make modeling data with R suck less better.

It’s actually pretty good

“Modeling” includes everything from classical statistical methods to machine learning.

The Tidyverse

The Tidyverse

Tidymodels

tidymodels.org

Tidy Modeling with R (tmwr.org)

Selected Modeling Packages

Loading the Meta-Package

What are our features?

What are our features?

What are our features?

What are our features?

What are our features?

What are our features?

What are our features?

What are our features?

What are our features?

What are our features?

Linear regression specification

Let’s fit it with…

Let’s fit it with…

Let’s fit it with…

Let’s fit it with…

Let’s fit it with…

Let’s fit it with…

Let’s fit it with…

A modeling workflow

Model tuning

Example: Predicting cognitive function

The data

Data splitting

Model and recipe

Model tuning via racing

Racing process

Check predictions

Check predictions

Logistic calibration

Isotonic calibration

Beta calibration

Does it work?

Exercise!

Picking a final model

Fitting the final model

Test set evaluation

Test set ROC curve

Test set calibration curve

Next steps

Other extensions

Thanks

Within-Package Inconsistency: `glmnet` Predictions

Numeric `glmnet` Predictions

`glmnet` predictions formats

`glmnet` predictions formats

`tidymodels.org`

Tidy Modeling with R (`tmwr.org`)
